17
*
NOTE: For location, see Instruction Sheet #4-2686, included in 6-1886 Kit.
NOTE: 6-1334 Catcher Adapter Kit must be installed before Grass catcher can be mounted.
6-1886 ACCESSORY, 38” SINGLE BAG GRASS CATCHER
(Model Year 97; Replaced 6-1249)
ITEM PART NO. DESCRIPTION
-- 6-1886 KIT, Single Bag Grass Catcher (Incl. Items 1 thru 45)
1 5-1948 TOP, Container (Includes #1-1910 Decal)
2 1-6108 SKIRT, Dust
3 4-7973 FRAME
4 3-7758 ROD, Bag
5 1-9251 BAG, Grass Catcher
-- 4-4726* BAFFLE
6 5-4395 ASSEMBLY, Tube/Strap (Includes Indented Items)
7 3-9478 TUBE, Grass
8 3-6404 NUT, #10-24 Weld (3)
9 3-6415 SCREW, #10-24 x 5/8” Pan Head (3)
10 9-1552 WASHER, 7/32” Flat (2)
11 3-6433 ASSEMBLY, Strap Mounting (3)
12 3-6422 WASHER, 3/16” Flat (3)
13 5-4388 ASSEMBLY, Adapter/Strap (Includes Indented Items)
14 5-9469 ADAPTER
15 3-6404 NUT, #10-24 Weld (2)
16 3-6433 ASSEMBLY, Strap Mounting (2)
17 3-6422 WASHER, 3/16” Flat (2)
18 9-1552 WASHER, 7/32” Flat (2)
19 3-6415 SCREW, #10-24 x 5/8” Pan Head (2)
20 3-6543 NUT, 5/16-18 “T”
21 9-1296 WASHER, 11/32” Flat
22 9-1833 SCREW, 5/16-18 x 5/8” Pan Head
23 5-4514* ASSEMBLY, Blade (Includes #4-4686 Decal)
24 6-1887 HARDWARE BAG (Includes Indented Items)
25 9-0492* NUT, 5/16-18 Wing (2)
26 9-1303* BOLT, 5/16-18 x 1” Short Neck Carriage, Grade 5 (2)
27 9-1575* NUT, 5/16-18 Hex Center Lock, Grade B or 5 (2)
28 9-1318* SCREW, 5/16-18 x 3/4” Hex Head Cap, Grade 5 (2)
29 3-6543* NUT, 5/16-18 “T” (2)
30 9-1296* WASHER, 11/32” Flat (7)
31 9-1833* SCREW, 5/16-18 x 5/8” Pan Head (2)
32 2-9840 WASHER, Faceted (5)
33 2-9841 PIN, 5/16 x 1-11/16” Clevis (2)
34 3-1725 LATCH, Grass Catcher
35 9-0532 SCREW, #10-32 x 1-1/16” Hex Head Cap, Grade 2
36 9-0376 NUT, #10-32 Hex Top Lock
37 9-1503 PIN, 3/32 x 1-1/2 Hair (2)
38 1-2556 CONNECTOR, Bag Rod
39 6-0480 KIT, Air Lift (Includes Indented Items)
40 3-7723 LIFTS, Air (2)
41 9-0228 SCREW, 5/16-24 x 21/32” Machine (6)
42 9-0391 WASHER, 5/16” Internal Tooth Lock (6)
43 9-0223 NUT, 5/16-24 Hex (6)
44 9-1296* WASHER, 11/32” Flat, Grade 5 (2)
45 6-3289 KIT, Catcher Debris Shield (Incl. items 46-49)
46 6-3287 SHIELD, Debris
47 9-0909 BOLT, 1/4-20 x 1-1/2” Hex (2)
48 9-1294 WASHER, 1/4” Flat (2)
49 9-1705 NUT, 1/4-20 Hex Top Lock (2)
LT SERIES (Small Frame) MANUAL No. 06613
