CONTENTS
LAWN TRACTOR MODEL IDENTIFICATION
Positive identification of the machine will be necessary. Identify the machine with the model
number to insure the correct kit is used for that model. The series number or letter of the
model number is used in this manual to match the correct kit with the correct model. Refer
to Owner’s Manual for correct Series number. The series number for all disc, gear and hydro
drive two piece frame models is 0, 1, 2. The series number for all gear and hydro drive one
piece frame models is A thru I. The Series number examples are as follows:
Lawn Tractor (Disc Drive Two Piece Frame) Example: LT12D330B - Series number is 0.
Lawn Tractor (Disc Drive Two Piece Frame) Example: LT115D411KV - Series number is 1.
Lawn Tractor (Gear Drive Two Piece Frame) Example: LT115G411KV - Series number is 1.
Lawn Tractor (Hydro Drive Two Piece Frame) Example: LT140H412KV - Series number is 2.
Lawn Tractor (Hydro Drive One Piece Frame) Example: LT160H42ABV - Series letter is A.
Lawn Tractor (Gear Drive One Piece Frame) Example: LT120G38AB - Series letter is A.
Lawn Tractor (Gear Drive One Piece Frame) Example: BH120G38BB - Series letter is B.
KIT No. DESCRIPTION PAGE
6-0609 Tire Chain (For 18” X 6.50” Tire) ..........................................................................4
6-1085 Tire Chain (For 18” X 8.50” Tire) ..........................................................................4
6-1399 Tire Chain (For 18” X 9.5” Tire) ............................................................................4
6-1333 Tire Chain (For 20” X 10” Tire) .............................................................................4
6-1245 Rear Weight .................................................................................................. 4 & 5
6-0870 Thatcherizer (LT12D Series) ........................................................................ 6 & 7
6-1247 Thatcherizer (1 Piece Frame Models) .......................................................... 8 & 9
6-0737 Anti-Scalp Wheel (33” Deck) .............................................................................10
6-0794 Anti-Scalp Wheel (41” Deck) .............................................................................10
6-1400 Anti-Scalp Wheel (33” Deck) .............................................................................11
6-3128 Anti-Scalp Wheel (48” Deck) .............................................................................11
6-0943 33” Single Bag Grass Catcher ............................................................... 12 & 13
6-1312 38” Single Bag Grass Catcher (For Hydro Drive Models) ....................... 14 & 15
6-1886 38” Single Bag Grass Catcher (Replaced 6-1249).................................. 16 & 17
6-0944 41 & 42” Single Bag Grass Catcher ....................................................... 18 & 19
6-3289 Debris Shield Kit, (For All Single Bag Catchers) ................. 14 & 15, 16 & 17, 19
6-3281 33” Twin Bag Grass Catcher (6-1334 Adapter Kit Required) .................. 20 & 21
6-1248 38” Twin Bag Grass Catcher (6-1334 Adapter Kit Required) .................. 22 & 23
6-1888 38” Twin Bag Grass Catcher (6-1334 Adapter Kit Required) .................. 22 & 23
6-0945 41” Twin Bag Grass Catcher................................................................... 24 & 25
6-3131 33” Clamshell Grass Catcher (6-1334 Adapter Kit Required) ................. 26 & 27
6-3126 38” Clamshell Grass Catcher (6-1334 Adapter Kit Required) ................. 28 & 29
6-1334 Grass Catcher Adapter (1 Piece Frame Models Series. A Thru D) ..................30
6-1068 Grass Catcher Adapter (Hydro and Gear Drive) ...............................................31
6-1311 Grass Catcher Adapter (Hydro Drive; w/20-10.00 X 8 Tires) ............................31
6-0860 Grass Catcher Adapter (LT12D Series)............................................................32
(continued on next page)
MANUAL No. 06613 LT SERIES (Small Frame)
