5-9
Parameter Menus
RS-232C Host Types
Three RS-232C hosts are set up with their own parameter default settings ( Table 5-2 ).
Selecting the ICL, Fujitsu, or Nixdorf RS-232C terminal sets the defaults listed below. These
defaults take precedence over standard defaults. So if you select Fujitsu RS-232C, then select
the standard defaults, the Fujitsu defaults still take precedence.
Table 5-2. Terminal Specific RS-232C
Parameter Standard ICL FUJITSU NIXDORF
Mode A/
Mode B
PDT
3300**
Transmit Code ID No Yes Yes Yes Yes
Data Transmission Format Data as is Data/Suffix Data/Suffix Data/Suffix STX/Data/
ETX/LRC
Suffix CR/LF
(7013) CR (1013) CR (1013) CR (1013) None
Baud Rate 9600 9600 9600 9600 19200
Parity None Even None Odd Even
Hardware Handshaking None RTS/CTS
Option 3 None RTS/CTS
Option 3 RTS/CTS
Standard
Software Handshaking None None None None ACK/NAK
Serial Response Time-out 2 Sec. 9.9 Sec. 2 Sec. 9.9 Sec. 9.9 sec.
Stop Bit Select One One One One One
ASCII Format 8-Bit 8-Bit 8-Bit 8-Bit 7-Bit
Beep On Disabled Disabled Disabled Disabled Disabled
RTS Line State Low High Low *Low = No
data to send Low
*In the Nixdorf Mode B, if CTS is Low, scanning is disabled. When CTS is High, the user can scan
bar codes.
**If Nixdorf Mode B or PDT 3300 is scanned without the scanner connected to the proper host,
it may appear unable to scan. If this happens, scan a different RS-232 host type within 5 seconds
of cycling power to the scanner.
