4-6
LS 400Xi Product Reference Guide
Pin-outs
Table 4-2. Pin-outs
Pin LS 4004I LS 4005I LS 4005I with EAS
1 Reserved Reserved Reserved
2 Power Power Power
3 Ground Ground Ground
4 Synapse Data Synapse Data Synapse Data
5 Synapse Clock Synapse Clock Synapse Clock
6 RxD B IBM SERIAL B IBM SERIAL
7 TxD A IBM SERIAL A IBM SERIAL
8 DTR Not used Shield
9 CTS Not used EAS 1
10 RTS Not used EAS 2
