2-2
LS 400Xi Product Reference Guide
2. Pull the boot up over the cable until just the connector is protruding ( Figure 2-1 ).
Figure 2-1. Scanner Cable
3. Plug the modular connector on the cable into the receptacle in the bottom of the LS
400Xi handle ( Figure 2-2 ). Listen for a click.
Figure 2-2. Plugging in the Modular Connector
4. Gently tug the cable to ensure the connector is properly secured.
