Plasma Screen Type
Reception Format
Reception Range
Power Source
Power Consumption
Model
NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial,
Digital Cable
VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper
and Ultra bands (191 channel frequency synthesizer system)
• Reception of channel A-5 ("95" of the TV set's on-screen cable channel
numbers) is not recommended for your TV set.
AC 120V, 60 Hz
TV: 369W
Receiver: 38W
Screen Size 42 inch / 107.5 cm
measured diagonally,
16:9 ratio
Speakers DD Speaker : (3 3/4 x 7 7/16 inch / 9.5 cm x 1 cm) oval x 2
Tweeter: (13/16 inch / 2 cm) round x 2
Woofer (5 1/8 x 2 9/16 / 13 cm x 6.5 cm) oval x 2
Audio Output 20W + 20W
Antenna Terminal
(VHF/UHF,
ATSC/DIGITAL
CABLE IN)
75 ohms (VHF/UHF)(F-type connector)
External Input Jacks
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance
Component Input
Jack
Y: 1Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
S-Video Input Jacks Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
AV CompuLink III
Jack
3.5 mm mini jack X 1
Digital–In HDMI jack x 1
Note: The Digital–In terminal is not compatible with picture signals of a
personal computer
Refer to "unpacking your TV", page 9
Dimensions (in)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(VARI/FIX)
50 inch / 127 cm
measured diagonally,
16:9 ratio
PD-42X795 PD-50X795
VARI: More than 0 to 1000mVrms (+2.2dBs)
FIX: 500mVrms (-4dBs) Low impedance (400 Hz when modulated 100%)
Optical Output
Digital Audio
Digital Out (optical) x 1
i.LINK In/Out Jack
TS IN/OUT (4-pin, S400) x 2
IEEE1394 compliant DTCP digital copy protection compatible
Subwoofer Output
Jack
More than 0 to 1000mVrms (+2.2dBs)
Low impedance (80 Hz when modulated 100%)
PC Input Jack Analog RGB D-SUB (15 pin) x 1
• PC signal is available. Refer to page 25 for details on the signals which
can be input.
TV: 468W
Receiver: 38W
TV: 45 3/4 x 28 7/8 x 4 1/4
TV: 116 x 73.1 x 10.8
TV: 53 1/4 x 33 x 4 3/8
TV: 135 x 83.6 x 11
TV: 83.6 / 38
Receiver: 17 1/4 x 2 7/8 x 12 3/8
Receiver: 43.5 x 7 x 31.3
TV: 112.2 / 51
Receiver: 9.5 / 4.3
Monitor/Recording
Output
Video: 1Vp-p, 75ohms
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Audio: 250mVrms (-10dBs)
Fs-18dB Low Impedance
Specifications subject to change without notice.
* Rating Label is pasted at the bottom of the Receiver Unit.
Specifications
