10
Read the following instructions and then attach the supplied stand to the TV.
WARNING: The TV is heavy. It should always be carried by at least two people. Attempting to
carry it by yourself may lead to it being dropped causing injuries and damage.
Required items: Phillips screwdriver
1. Attach the screws (A) to the back of the TV.
2. Attach the TV to the stand. Insert the heads of
the screws (A) into the top of the stand bar and
temporarily secure the TV to the stand.
3. Secure the TV to the stand with the screws (B).
4. Insert the cover to the stand and fix with the
screws (C).
5. Remove the paper from the bottom of the cable
clamp and attach the cable clamp to the stand.
• Clamp the system cable and power cord using the
cable clamp after connecting the system cable and
the power cord to the TV.
Screw (A)
Stand
Screw (B) Screw (B)
Screw (C)
Cover
Cable clamp
Quick Setup Attaching the stand to the TV
