AT-140GE
- 65 -
LUT Controls
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value Description
Default
value
0xA200 LUT Enable LUTEnable
R
W
4
0xD000
|
0xD7FC
LUT Value (Red) LUTValue[Red]
R
W
4 0 ～ 65535 0
0xD800
|
0xDFFC LUT Value(Green,Bayer or
Monochrome)
LUTValue[Green]
R
W
4 0 ～ 65535 0
0xE000
|
0xD7FC
LUT Value (Blue) LUTValue[Blue]
R
W
4 0 ～ 65535 0
Event Generation
Address Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value Description
Default
value
0xA610
Event Selector
Acquisition Trigger
GevEventtreigger
RW
4
Selector Value
0
Event message ON/OFF
0
Exposure Start GevEventStartOfExposure 1 0
Exposure End GevEventEndOfExposure 2 0
Frame Transfer Start GevEventStartOfTransfer 3 0
Frame Transfer End GevEventEndOfTransfer 4 0
Any Lines Any Edges AnyLineAynyEdge 17 0
Updated All Features UpdatedAllFeatures 18 1
Processing Done ProcessingDone 19 1
Video Parameters
Changed
VideoParamsChanged 20 1
Opposite Channel
Parameters changed
DioTrigParamsChanged 21 1
Device Reset DeviceReset 31 1
Event Notification EventNotification
0=Disable
1=Enable
User Sets
Address Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value Description
Default
value
0xA300 User Set Save UserSetSave W 4
1=User area1
Allows use to save all
camera settings. Last
used area number
becomes new default.
1
0xA304 User Set Load UserSetLoad W 4
0=Factory area
1=User area1
Allow the user to recall
all camera settings.
0
0xA308 User Set Selector UserSetSelector RW 4
When receiving
following commands,
store the parameters
0xA300
0xA304
Check the used data,
0=Factory or1=User
0
