AT-140GE
- 59 -
0xA184 Matrix RG MatrixRG RW 4 -2048 ～ 2047 0
0xA188 Matrix RB MatrixRB RW 4 -2048 ～ 2047 0
0xA18C Matrix GR MatrixGR RW 4 -2048 ～ 2047 0
0xA190 Matrix GG MatrixGG RW 4 -2048 ～ 2047 1024
0xA194 Matrix GB MatrixGB RW 4 -2048 ～ 2047 0
0xA198 Matrix BR MatrixBR RW 4 -2048 ～ 2047 0
0xA19C Matrix BR MatrixBG RW 4 -2048 ～ 2047 0
0xA1A0 Matrix BB MatrixBB RW 4 -2048 ～ 2047 1024
Digital Processing
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value Description
Default
value
0xA0F0 Gamma Set(RGB) GammaSet[RGB] RW 4
0=OFF 1=0.45
2=0.6 3=LUT
0
0xA11C
Shading Correction
Enable
ShadingCorrectionEnable RW 4
0=OFF
1=On
0
0xA120 Shading Correction Mode ShadingCorrectionMode R 4
0=Flat shading
1=Color shading
0xA128 Blemish Reduction Enable BlemishReductionEnable RW 4
0=Disable
1=Black blemish
2=White blemish
3=Both blemish
0
0xA130
Perform Flat Shading
Calibration PerformFlatShadingCalibr
ation
WO 4
Command=0
Perform Color Shading
Calibration PerformColrShadingCalibr
ation
Command=1
0x10000
|
0x10236
Shading Data Selector
(Red) ShadingDataSelector[Red
_Mono]
R 4 0 ～ 65535 Index=0～566 0
0x11000
|
0x11236
Shading Data Selector
(Green) ShadingDataSelector[Gree
n]
R 4 0 ～ 65535 Index=0～566 0
0x12000
|
0x12236
Shading Data Selector
(Blue) ShadingDataSelector[Blue
]
R 4 0 ～ 65535 Index=0～566 0
0xA138
Perform Black Blemish
Reduction Calibration PerformBlackBlemishCali
bration
W 4
Command=0
Perform White Blemish
Reduction Calibration PerformWhiteBlemishCali
bration
Command=1
0x13000
|
0x1307
C
Black Blemish of Red BlackBlemishRed RW 4 0 ～ 4294967295 Index=0～31 0
0x13080
|
0x130F
C
White Blemish of Red WhiteBlemishRed RW 4 0 ～ 4294967295
Index=0～31
0
0x13100
|
0x1317
C
Black Blemish of Green BlackBlemishGreen RW 4 0 ～ 4294967295 Index=0～31 0
0x13180
|
0x131F
C
White Blemish of Green WhiteBlemishGreen RW 4 0 ～ 4294967295
Index=0～31
0
