AT-140GE
- 57 -
0xA020
Exposure Time (us) to
Red
ExposureTimeAbsRed RW 4 25 to 48136( OFF)
Set exposure time by micro
second (for R channel)
48136
0xA024
Exposure Time (us) to
Green
ExposureTimeAbsGreen RW 4 25 to 48136( OFF)
Set exposure time by micro
second (for G channel)
48136
0xA028
Exposure Time (us) to
Blue
ExposureTimeAbsBlue RW 4 25 to 48136( OFF)
Set exposure time by micro
second (for B channel)
48136
0xA030 Auto exposure value AutoExposureValue R 4
Exposure time on Auto
exposure mode
0xA040 Exposure Mode ExposureMode RW 4
00=Continuous trigger
01=Edge pre-select
02=Pulse-width control
04=RCT mode
09=Sequential EPS
trigger
17=Delayed readout EPS
trigger
18=Delayed readout
PWC trigger
32=PIV mode 1
64=PIV mode 2
128=PIV mode 3
0
0xB060 Camera Trigger 0 CameraTrigger0
Trigger Source
Bit31 ~ Bit25
Bit24:Trigger Activation
0=Rising Edge(Active
High)
1=Falling Edge(Active
Low) Trigger Source
127=OFF
9=Line4-OpticalIn 1
10=Line5-optical In 2
12=Line6-TTL In 1
13=Line7-TTL In 2
11=Line8-LVDS In
16=Pulse Generator0
17=Pulse Generator1
20=User Output 0
(Software trigger 0)
21=User Output1
(Software trigger10)
22=User Output 2
(software trigger 2)
23=User Output 3
(Software trigger 3)
Add 0x80 makes「Active
Low」
127
0xB064 Camera Trigger 1 CameraTrigger1
0xB0A0 Time Stamp Reset Trigger TimeStampReset
0xB0A4
Sequence Table Reset
Trigger
SequenceTableReset
0xA04C Smearless Enable SmearlessEnable RW 4 0:OFF 1:ON
0xA048
LVAL Sync/Async
Accumulation
LVALSyncAccumulation RW 4 0=Auto 1:Sync 2=Async
Video Control
Address
Display Name
(JAI Control Tool)
GenICam name
Read /
Write
Size Value / Range of value Description
Default
value
0xA050 Analog All AnalogAll RW 4 -89 ～ 341
Analog all
‐89(－3dB) 341(＋12dB)
1 step=0.0358dB
Value 0＝0dB
0
0xA054 Analog Red AnalogRed RW 4 -200 ～ 200
Analog all
‐200(－6dB) 200(＋6dB)
1 step=0.0358dB
Value 0＝0dB
0
0xA058 Analog Blue AnalogBlue RW 4 -200 ～ 300
Analog all
‐200(－6dB) 200(＋6dB)
1 step=0.0358dB
0
