To wall outlet
Power cord
(supplied)
When all the connections
are completed
Playback component such as a PC or VCR
* For component video connection, connect only to the green, blue, and red
terminals.
To stereo audio
output terminals
To video output
terminal (BNC)
To S-video
output terminal
To audio
output
terminal
To RGB output
terminal
To digital
output terminal
D-
sub 15 pin cable
DV
I-D cable
St
er
eo mini jack cable
S-
video cable
BNC cable St
er
eo audio
cable
Connect the VIDEO IN A OUT terminal to the video input terminal of another monitor, etc.
CAUTION
• Since the IN terminal and OUT terminal are loop-through terminals, the devices connected to the OUT terminal should be correctly
terminated. Otherwise, pictures become abnormally bright or the display screen gets affected abnormally.
R L
Playback component such as a VCR
To component video or RGB *
output terminal (BNC)
D-
sub 15 pin – BNC
con
version cable
or
Red Blue
Gr
een
Synchr
oniz
ed
sig
nal (H)
Synchr
oniz
ed
sig
nal (
V
)
