19
When mounting of this unit is required, do so by removing the 4 feet and make use of the 4 screw holes (M8 nuts) at
the bottom of this unit. Allow sufficient space around the air inlets to avoid blocking them.
Mounting this Unit
Air Inlet
Precautions for Ceiling-mount
● To ceiling-mount this unit, special expertise and
techniques are necessary. Be sure to ask your dealer
(or a specialist) to perform mounting (to ceilings, etc.).
● Do not mount at places that may be subjected to
vibration and shock.
● Depth of the screw holes (screw length) is 30 mm. Use
screws shorter than 30 mm but longer than 19 mm.
Otherwise, the screws may damage the internal parts
of this unit and cause malfunction.
● Install at a safe place in case this unit or a part of it may
drop. If the light-source lamp is broken, small pieces of
glass from the mesh of the filter may appear outside
this unit.
ENGLISH
