52
Detailed setting
It is possible to output B&W/Color switching signal from the AUX terminal on
the back of this camera.
B&W/Color switching signal is output by setting both the AUX MODE and
B&W/COLOR items.
Ⅵ Set the AUX MODE item to AB&W OUTB
1.
Select the item AUX FUNCTION on the main menu screen and press
the SET button.
The AUX FUNCTION screen is displayed.
2.
Press the SELECTOR switch up or down ( J, K) and select AUX MODE.
3.
Press the SELECTOR switch left or right ( H, I) and set to B&W OUT.
4.
Press the MENU button twice.
The setting is complete and the screen returns to the normal screen.
Output of B&W/Color switching signal
MENU
E AUX FUNCTION..
TITLE/VIDEO..
DISPLAY..
LL ADJUSTMENT..
MAINTENANCE..
FACTORY SETTINGS..
SUB MENU
AUX FUNCTION
E AUX MODE B&W OUT
INPUT POLARITY - - -
Main menu screen
AUX FUNCTION screen
