Mounting the camera-mounting bracket on top of the camera
The camera-mounting bracket is originally mounted at the bottom of the
camera before shipment but it can also be mounted on top of the camera.
Mounting the camera (continued)
IRIS
VIDEO
DC
LEVEL
COLOR VIDEO
1
2
3
Camera-mounting
bracket
Camera-mounting
bracket fastening screws
To mount the camera-
mounting bracket on top of
the camera, use the screw
holes on the back panel.
