41
Item Functions and settings
GAIN (continued)
MAX
GAIN This item sets a maximum gain of the AGC (Automatic
Gain Control).
0(OFF) : No AGC function.
HIGH
: Increase the gain up to a maximum of 26dB
according to the illumination of an object.
SUPER : Increase the gain up to a maximum of 32dB
according to the illumination of an object.
[Default setting: HIGH]
Memo:
● When the MODE item of B&W/COLOR is set to
AAUTOB, the MODE item becomes AAGCB [(AGC) is
displayed] but AHIGH/SUPERB can be selected.
When it is set to A0(OFF)B, AHIGHB will be selected
automatically.
● When MODE item is set to AFIXEDB, A- - -B will be
displayed and settings is disabled.
FIX
GAIN This sets the value of fixed gain when MODE is set to
AFIXEDB.
[Setting: 0 to 20]
[Default setting: 10]
Memo:
● When MODE item is set to AAGCB, A- - -B will be
displayed and settings is disabled.
