Jackson Hot Water Sanitizing Undercounter Dishmachines JPX-200 - Manual (Page 34)

ITEM QTY DESCRIPTION Mfg. No.
01 1 Nut, Cover 2020-142-28-01
02 1 Cover, Rinse Element 2020-142-27-99
03 1 Catch, Ball Assembly 2020-162-27-31
04 1 Switch, Micro Door with Assembly 2020-162-27-23
05 2 Corner Piece, External 2020-162-27-33
06 2 Corner Piece, Internal 2020-162-27-32
07 1 Dish Rack 2020-162-68-14
08 1 Plate Rack 2020-162-68-15
09 1 Terminal Block 2020-162-27-20
10 2 Contactor, 240 Volt, 3NO/1NC 2020-142-28-54
11 2 Contactor, 12 Volt Coil, B6C 2020-162-28-53
12 1 Contactor, Safety 240 Volt 2020-162-68-16
MISCELLANEOUS
31
01
02
10
10
11
11
Front View
12
Bottom Right Side View
11
09
07
08
03 04 05 *06
J
P
X
1
6
0
