DIMENSIONS of the JPX-160
22
2 1/2” MIN. WALL CLEARANCE A. 1/2” FNPT 140BF. WATER CONNECTION
B. DRAIN HOSE CONNECTION FOR PUMPED DRAIN FROM THE
UNIT. DISCHARGE HEIGHT MUST BE MAINTAINED. UNIT SUP-
PLIED WITH 1” I.D. X 1 1/2” O.D. X 6’-0” LONG FLEXIBLE HOSE.
C. ELECTRICAL CONNECTION
20”
29 5/8”
13 7/16”
33 7/16”
20”
5 1/4”
2 3/4”
5”
14”
INSIDE
CLEARANCE
REAR VIEW OF UNIT
SHOWING CONNECTIONS
19”
19”
2 1/2”
24” B
A
C
DOOR IN OPEN POSITION
J
P
X
1
6
0
