ITEM
QTY
DESCRIPTION
Mfg. No.
01
1
Rinse Tank
2020-162-28-28
02
2
Terminal Guard
2020-162-28-00
03
1
Nut, Thermal Switch
2020-162-27-96
04
1
Thermostat, High Limit, Rinse Tank
2020-162-27-17
05
2
Hose Clamp
2020-162-27-59
06
1
Hose, Drain Pump Inlet
2020-162-28-06
07
1
Nut, 1” Plastic
2020-142-27-64
08
1
Pump Inlet Hose
2020-162-27-90
09
1
Nut, Plastic
2020-162-27-91
10
4
Hose Clamp
2020-162-27-62
11
4
Foot, Machine
2020-162-27-43
12
1
Thermostat
2020-162-68-13
13
3
Nut, Element Securing
2020-162-27-93
14
1
Heater, Rinse
2020-142-28-49
15
1
Gasket, Heater Element
2020-142-27-92
16
1
Pump Head, Rinse Agent
2020-162-28-31
17
1
Bracket, Soap Pump
2020-162-27-75
18
1
Outlet & Pipe
2020-162-26-79
19
1
Hose, Rinse
2020-162-28-24
20
1
Pump Head, Soap
2020-162-28-30
21
1
Hose, Rinse
2020-162-28-24
22
1
Solenoid Valve, 12 Volts
2020-162-27-03
23
2
Motor, Soap/Rinse Aid Pump
2020-162-28-33
24
1
Washer, Fiber
2020-162-28-05
25
1
Bolt, Drain
2020-162-28-04
26
1
Pump, Drain
2020-162-28-56
27
1
Wash Pump
2020-162-28-23
28
1
Hose, Rinse
2020-162-28-24
29
1
Tee
2020-162-27-26
30
1
Hose, Gray Waste
2020-162-28-57
FRONT AND BOTTOM VIEW (CONTINUED)
