Controls
a Mode Button [MODE] (੬ pg. 16)
b Recording Mode Dial (੬ pg. 16, 31 – 32)
c Lock Button (੬ pg. 16)
d Power Switch [OFF, , ] ( ੬ pg. 16)
e Battery/CF Card Cover Open Switch [OPEN]
( ੬ pg. 14, 17)
f Delete Button [ ] (੬ pg. 40)
g Zoom Lever [T/W] (੬ pg. 21, 25)
Speaker Volume Control ( ੬ pg. 22, 30)
h Recording Start/Stop Button
( ੬ pg. 20, 25, 29)
i Play/Pause Button [49] (੬ pg. 22, 27, 30)
j Multi-Controller
w: Reverse Search [w ( 3)] (੬ pg. 23)/Left
[w]/Flash [ ] (੬ pg. 26)
r: Reverse Skip [r ( 2)] (੬ pg. 23)/Up [r]/
Backlight Compensation [ ] ( ੬ pg. 31)/
Spot Exposure Control ( ੬ pg. 31)
e: Forward Search [e ( 5)] (੬ pg. 23)/
Right [e]/Continuous Shooting/Bracket
Shooting [
/ ] ( ੬ pg. 26, 33)
t: Forward Skip [t ( 6)] (੬ pg. 23)/Down
[t]/Manual Set [ SET] ( ੬ pg. 34)
k Focus Button [FOCUS] (੬ pg. 33)
l Information Button [INFO] (੬ pg. 38)
m Menu Button [MENU] (੬ pg. 48)
n Flash Open Switch [FLASH OPEN]
( ੬ pg. 26)
o Manual Focus Ring (੬ pg. 33)
p Lens Hood (੬ pg. 8)
Connectors
The connectors are located beneath the covers.
Q USB (Universal Serial Bus) Connector (Refer
to the software installation and USB
connection guide.)
R Headphone Connector [ ] (੬ pg. 9)
S S-Video/Audio/Video Output Connector [AV]
( ੬ pg. 24)
T DC Input Connector [DC] (੬ pg. 14)
Indicators
U Power/Charge Lamp ( ੬ pg. 14, 16)
V Access Lamp (Lights up or blinks when you
access to any files. Do not turn off the power
or remove the battery pack/AC adapter while
accessing to files during recording or
playback.)
W Mode Lamp [ (video), (still image),
(voice)] ( ੬ pg. 16)
Other Parts
X Stereo Microphone
Y Speaker (
੬ pg. 22)
Z LCD Monitor
b Battery/CF Card Cover (
੬ pg. 14, 17)
c Flash
d Camera Sensor
e Lens
f SD Card Cover (
੬ pg. 18)
g Tripod Mounting Socket
h Strap Fastener Eyelet (
੬ pg. 8)
i Strap Eyelet ( ੬ pg. 8)
j Reset Hole ( ੬ pg. 52)
