Fuses
183
LUGGAGE COMPARTMENT FUSE BOX
F53 20A Yellow Rear cigar lighter.
F54 - - -
F55 20A Yellow Rear accessory socket.
F56 10A Red RCM/OCS.
F57 10A Red Glove box, glove box lamp, front and rear overhead consoles,
sun visor lamps, vanity lamps.
F58 - - -
F59 - - -
F60 - - -
F61 10A Red IAU, cluster, cluster fan.
F62 10A Red Climate control module.
F63 20A Yellow Front accessory socket.
F64 15A Blue IAM (head unit).
F65 - - -
F66 5A Tan OBD 2.
F67 - - -
F68 10A Red DAB, TVM.
F69 15A Blue HLDF.
Fuse
No Rating
(amps) Fuse
Colour Circuit
F1 40A Orange LH seat belt retract module.
F2 15A Blue CVD ECU, ACC.
F3 5A Tan PAM, RH blind spot monitor, rear view mirror.
F4 10A Red Chassis control module.
F5 20A Yellow Air suspension.
F6 30A Green Electronic parking brake (EPB).
F7 40A Orange RH seat belt retractor module.
F8 30A Green Fuel pump.
F9 40A Orange Power amp.
F10 - - -
Fuse No Rating
(amps)
Fuse
Colour Circuit
