Built-in viewer (continued) – JVC VN-685U User Manual
Page 118
118
JPEG Viewer Settings (continued)
Ⅵ Stream
For specifying settings for receiving JPEG stream.
A
Stream
For selecting the protocol when the viewer acquires data from the
camera.
When
AHTTPB is selected, lost packets are recovered via resending.
Camera may be monitored using multiple viewers when
AMulticastB is
selected. When playing back via multicast, start multicast sending on the
[Streaming] page.
[Streaming Page] (
Note:
● When Built-in Viewer is launched with AMulticastB specified, a
Windows firewall warning may appear. In this case, select
AunblockB
and proceed.
● If AblockB is selected, the Windows firewall will block the multicast
stream and playback of
AMulticastB by the viewer will fail.
B
HTTP Port
You can change the HTTP port number.
The default port number setting is
A80B.
Specify the same value as the parameter that is set on the [Protocol]
page of the camera. (
C
Frame Rate
For selecting the acquisition frame rate of the viewer.
Selecting a large frame rate will increase the processing load of the
computer on which the viewer is running.
[Setting values:30, 25, 15, 10, 7.5, 6, 5, 3, 2, 1, 1/2, 1/3, 1/5, 1/10, 1/15,
1/20, 1/30, 1/60]
Note:
● Set to a rate such that the CPU burden of the computer does not
exceed 80 %. If the CPU is overloaded, the computer may not
function properly.
D
Multicast IP
Address
You can change the multicast IP address.
The default IP address setting is
A225.0.1.1B.
E
Multicast Port
You can change the multicast port number.
The default port number setting is
A49152B.
Memo
:
● This is enabled when [Start] is selected for the[JPEG] [Control] item
on the [Streaming] page.
● Specify the same value as the parameter that is set on the
[Streaming] page of the camera. (
Other
A
Folder Name
For specifying the name of the folder in which the captured files are
stored. (When the viewer is installed:
AVN-V685B(VN-V685U),AVN-
V686B
B(VN-V686BU/VN-V686WPBU)
