61
H TCP/UDP TCP/UDP IP Address
: For entering the address when alarm action notification is
to be sent via TCP or UDP. (IP or FQDN)
TCP/UDP Port Number
: For entering the port number when alarm action
notification is to be sent via TCP or UDP. (1-65535)
TCP/UDP Data
: For entering the data to send during TCP or UDP
notification. Input up to 127 alphanumeric characters.
I Alarm Output
Duration For setting the alarm output time from the alarm output terminal.
When this is set to
A0B, it is not possible to revert back to break (or make)
after changing to make (or break).
[Setting range:0/100msec to 5000msec]
J Time Filter For specifying the alarm action with respect to each day of the week and
setting the corresponding time of the day.
Applicable day of week
: Sunday, Monday, Tuesday, Wednesday, Thursday, Friday,
Saturday
Alarm action : Mask span
Unmask span
Mask All
Unmask All
Applicable time period
: For specifying the Start and End time in hours and
minutes.
