11
HD5212
Tuner Operation
Press the SRC button (2) to switch to HD RADIO mode.
About HD Radio™ Technology
HD Radio technology allows CD-quality digital broadcasting of your local
AM and FM radio stations. HD Radio broadcasts can include multiple
channels on the same frequency, which is called multicasting. With
multicasting, you can receive up to three additional multicast channels:
HD2, HD3, HD4. With your HD5212 radio, you will receive HD Radio digital
broadcasts automatically when tuned to a station that offers HD Radio
technology.
Select a Band
Press the BAND button (3) to change between three FM bands and one AM
band. Each band stores up to six preset stations.
Tuning
When tuning to an HD Radio channel, “LINKING” will appear on the LCD
while the initial digital information is received. Once linked, “Hd1” appears in
the bottom left corner of the LCD.
NOTE: Not all FM or AM stations offer HD Radio (digital) broadcasting.
You will receive both analog and digital stations with the HD5212.
Manual Tuning
Press the TUNE/CH >> (10) or TUNE/CH << (11) button for more than three
seconds to enter manual tuning mode, then press the TUNE/CH >> or
TUNE/CH << buttons to move the radio frequency number up or down one
step.
Auto Seek Tuning
Press the TUNE/CH >> (10) or TUNE/CH << (11) button to automatically
seek the next station.
Mono/Stereo
Press the MONO button (19) to select mono or stereo reception for analog
radio stations. You can sometimes improve reception of weak stations by
selecting mono operation. When in stereo mode, the “ST” icon (18) appears
on the display.
HD Radio Multicast Channels
To tune to an HD Radio multicast channel, tune to the main signal and then
press the SELECT button (5). If a subchannel is available, the
corresponding multicasting number appears in the bottom left corner of the
LCD.
Preset Stations
Six numbered preset buttons store and recall stations for each band.
Store a Station
Select a band (if needed), then select a station. Hold a preset button (13-18)
for three seconds. The preset number will appear in the display.
PRESS
RPT SHF SCN 1 2 3 4 5 6
SEL
CAT/DIR AUX IN
MONO DISP EQ
BAND
SRC
TUNE/CH
MUTE
A~Z
0~9
PS
ENTER
IPOD
FILE/FOLDER HD5212 SAT
READY
1 2 4 7
10
11
3
5 6 8 9 20
12
19 21
13 14 16 15 17 18 22
PRESS
RPT SHF SCN 1 2 3 4 5 6
SEL
CAT/DIR AUX IN
MONO DISP EQ
BAND
SRC
TUNE/CH
MUTE
A~Z
0~9
PS
ENTER
IPOD
FILE/FOLDER HD5212 SAT
READY
PRESS AND HOLD
PRESET NUMBER APPEARS
