Parts Identification
Front Panel
See pages in the parentheses for details.
Display
1 Sound signal indicators (11, 13, 18)
• PRO LOGIC, DOLBY DIGITAL, DTS,
and LINEAR PCM
2 TITLE indicator (26)
3 Tuner mode indicators (14, 44, 45)
• TUNED and ST (stereo)
4 PROGRAM indicator (31, 37, 45)
D I G I T A L
S U R R O U N D
D I G I T A L
COMPACT
DIGITAL VIDEO
STANDBY
AUDIO/FM MODE
DSP VOLUME SOURCE
DVD DIGITAL THEATER SYSTEM TH-A5
STANDBY/ON
1 2 3 4 5 6 7 8
q w p 9
See pages in the parentheses for details.
Front Panel
1 STANDBY/ON button and STANDBY lamp (10 – 14)
2 AUDIO/FM MODE button (28, 38, 45)
3 Multi operation buttons
• 4, ¢, and 7
4 Disc tray (10, 12)
5
0 (open/close) button (10 – 13, 32, 37, 41)
• Pressing this button also turns on the power and
changes the source to the DVD player.
6 Display window
7 Remote sensor
8
3/8 (play/pause) button (10, 12, 26, 41)
• Pressing this button also turns on the power and
changes the source to the DVD player.
9 DSP button (11, 13, 23)
p VOLUME + and – buttons (10, 12, 14)
q SOURCE button (14, 15, 44, 45)
w Illumination lamp (10, 12, 14)
5 DSP indicator (23)
6 PBC (Play Back Control) indicator (34, 35)
7 Frequency unit indicators
• MHz (for FM station) and kHz (for AM station)
8 Audio channel indicators
• Indicates audio channels currently being played back.
9 Main display
Display window
1 2 3 4 5 6 7
L C R
LFE
LS S RS
LINEAR PCM
ST
TITLE
TUNED PROGRAM PBC MHz
kHz DSP
8 9
