54
English
Specifications
Center unit (XV-THA5)
Amplifier section
Front/Center/Rear:
35 watts per channel, min. RMS at 6 ohms as 1 kHz,
with no more than 10 % total harmonic distortion.
Subwoofer:
60 watts per channel, min. RMS at 3 ohms as 100 Hz,
with no more than 10 % total harmonic distortion.
Audio section
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
AUX (“ANALOG IN”): 500 mV/47 k
Ω
Digital input:
AUX (“DIGITAL IN”): Optical: –21 dBm to –15 dBm
(with sampling frequency—32 kHz,
44.1 kHz, 48 kHz)
Video section
Color System:
NTSC
Horizontal Resolution: 480 lines
Signal-to-Noise Ratio: 68 dB
Output Level
Composite: 1.0 V(p-p)/75
Ω
S-video-Y: 1.0 V(p-p)/75
Ω
S-video-C: 0.286 V(p-p)/75
Ω
Component-Y: 1.0 V(p-p)/75
Ω
Component-P
B
/P
R
: 0.7 V(p-p)/75
Ω
Tuner section
Tuning Range
FM : 87.5 MHz – 108.0 MHz
AM : 530 kHz – 1 710 kHz
Usable Sensitivity
FM: 8.0 dBf (0.9 µV/75
Ω)
AM loop antenna: 650 µV/m
General
Power Requirements:
AC 120 V
, 60 Hz
Power Consumption:
120 W (at operation)
2 W (in standby mode)
Dimensions (W
× H × D): 350 mm × 80 mm × 300 mm
(13
13
/
16
in.
× 3
3
/
16
in.
× 11
13
/
16
in.)
Mass:
6.3 kg (13.9 lbs)
Subwoofer (SP-WA5)
Speaker:
20 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 60 W
Impedance:
3
Ω
Frequency Range:
25 Hz to 200 Hz
Dimensions (W
× H × D) 219 mm × 324 mm × 320 mm
(8
5
/
8
in.
× 12
13
/
16
in.
× 12
5
/
8
in.)
Mass:
6.2 kg (13.7 lbs)
Satellite Speakers (SP-XSA5)
Speakers:
7 cm
× 4 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 35 W
Impedance:
6
Ω
Frequency Range:
90 Hz to 20 kHz
Dimensions (W
× H × D) 65 mm × 144 mm × 105 mm
(2
9
/
16
in.
× 5
11
/
16
in.
× 4
3
/
16
in.)
Mass:
420 g (0.93 lbs)
Center Speaker (SP-XCA5)
Speakers:
7 cm
× 4 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 35 W
Impedance:
6
Ω
Frequency Range:
90 Hz to 20 kHz
Dimensions (W
× H × D) 143 mm × 67 mm × 106 mm
(5
11
/
16
in.
× 2
11
/
16
in.
× 4
3
/
16
in.)
Mass:
420 g (0.93 lbs)
Designs & specifications are subject to change without notice.
