Intel® IQ80219 General Purpose PCI Processor Evaluation Platform
Hardware Reference Section
3.8.8 Mictor J3C1
Warning: Be sure to fully understand the pin assignments of the particular logic analyzer being used before
connecting to the Intel
®
IQ80219 evaluation platform board. When voltage is applied, particularly
to a NC pin, hardware damage can be incurred.
Table 21. Micor J3C1 Signal/Pins
Schematic Signal Name
Mictor Pin
Name
Mictor Pin
Name
Schematic Signal Name
1 2
3 4
5 6
S_AD<63> 7 8 S_AD<47>
S_AD<62> 9 10 S_AD<46>
S_AD<61> 11 12 S_AD<45>
S_AD<60> 13 14 S_AD<44>
S_AD<59> 15 16 S_AD<43>
S_AD<58> 17 18 S_AD<42>
S_AD<57> 19 20 S_AD<41>
S_AD<56> 21 22 S_AD<40>
S_AD<55> 23 24 S_AD<39>
S_AD<54> 25 26 S_AD<38>
S_AD<53> 27 28 S_AD<37>
S_AD<52> 29 30 S_AD<36>
S_AD<51> 31 32 S_AD<35>
S_AD<50> 33 34 S_AD<34>
S_AD<49> 35 36 S_AD<33>
S_AD<48> 37 38 S_AD<32>
