Interface Test

A screen similar to the following is displayed for the interface test.

IBM REALTIME INTERFACE CO-PROCESSOR
AND X.25 INTERFACE CO-PROCESSOR

_____________________________________________________

PRESENT |

| STG

| PWR

| L

| B | PORTS

____

| CARD | SIZE | ON

| V

| U |

__________|

CARD|

| ADDR | KB

| ERR

| L

| S |

| ADAPTER

____|___|______|______|______|____|___|___|__________|

| Y | 2A | 512

| 1 |32 | | V.24

| 1 | V.35

| 2 | X.21

|____|___|______|______|______|____|___|___|__________|

EXTERNAL WRAP TESTS
SELECT FROM THE PORTS COLUMN AN
INTERFACE ( -2) TO BE TESTED
OR PRESS 9 TO SKIP EXTERNAL WRAP TESTS?

Note: You can test the PCI co-processor adapter with or without the

37-pin wrap plug (shown in “Cables and Wrap Plugs” on
page 4-23). The wrap plug lets you test the electrical
interfaces.

Problem Determination Procedures

4-13
