X.21 bis (V.24) Connector Information

The X.21

bis (V.24) pin assignments for the 37-pin connector on the

PCI co-processor adapter and the corresponding pin assignments for
the 25-pin connector on the optional adapter cable are listed in
Table 3-2. (The pin positions on the connector are shown under
“Pin Numbers” on page 3-1.)

Table

3-2. X.21 bis (V.24) Interface Pin

Assignments

Signal
Name

37-Pin
Connector

25-Pin
Connector

TXD

2

2

RXD

3

3

RTS

4

4

CTS

5

5

DSR

6

6

GND

7

7

CD

8

8

DTR

20

20

RLBT

21

21

RI

22

22

TX CLK IN

24

15

TM

25

25

RX CLK

26

17

LLBT

27

18

Note: Pin 27 can be used as either the
EIA-232 signal, HRS, or the V.24 signal,
LLBT.

Connector Information

3-3
