X.21 bis (V.35) Connector Information

The X.21

bis (V.35) pin assignments for the 37-pin connector on the

PCI co-processor adapter and the corresponding pin assignments for
the 34-pin connector on the optional adapter cable are listed in
Table 3-3. (The pin positions on the connector are shown under
“Pin Numbers” on page 3-1.)

Table

3-3. X.21 bis (V.35) Interface Pin

Assignments

Signal
Name

37-Pin
Connector

34-Pin
Connector

RTS

4

C

CTS

5

D

DSR

6

E

GND

7

B

CD

8

F

RX CLK (B)

16

X

TXD (B)

17

S

TX CLK IN (B)

18

AA

RXD (B)

19

T

DTR

20

H

RI

22

J

RX CLK (A)

34

V

TXD (A)

35

P

TX CLK IN (A)

36

Y

RXD (A)

37

R

3-4

X.25 Co-Processor PCI GTO
