DLP Projector – User’s Manual
– 7 –
I TEM L ABEL D ESCRIPTION S EE PAGE :
1. Power ON Turn the projector on 9
2. LED indicator Only lights when the remote keys are pressed
3. Display Mode Choose a suitable preset mode for usage environment
4. Contrast Display the Contrast setting bar and use the right and left keys to adjust
5. Brightness
Display the Brightness setting bar and use the right and left keys to ad-
just.
6. Left cursor
When the OSD is displayed, this button navigates to the
left. When USB has been connected to the projector
and PC, the previous presentation slide is displayed
13
7. Menu Display the OSD menu
8. Auto image Re-synchronize the PC image
9. Overscan
Adjust overscan
10. Source-1 VGA
11. Source-4 S-Video
12. Source-7 NA
13. Power OFF Turn the projector off 9
14. Source Display the source menu
15. Info Display projector information
16. Mute Mute the audio
17.
Up cursor /
Keystone+ When the OSD is displayed, this button navigates up the
menu. Otherwise it adjusts keystone
18. Select Enter and confirm settings in the OSD
19. Right cursor
When the OSD is displayed, this button navigates to the
right. When USB has been connected to the projector
and PC, the next presentation slide is displayed
20.
Down cursor /
Keystone - When the OSD is displayed, this button navigates down
the menu. Otherwise it adjusts keystone
13
21. Resize Change the image aspect ratio
22. Blank Blank the screen
23. Volume+ Increase the volume
24. Freeze Freeze video
25. Volume- Decrease the volume
26. Source-3 HDMI 2
27. Source-2 HDMI 1
28. Source-6 NA
29. Source-5 Composite
30. Light Turn the remote control backlight on or off
31. Source-8 NA
