DLP Projector – User’s Manual
Bottom view
I TEM L ABEL D ESCRIPTION S EE PAGE :
1. Leveling foot Rotate leveling foot to adjust angle position. 10
2. Ceiling support holes
Only use with an InFocus ceiling mount system (p/n PRJ-MNT-UNIV).
See your InFocus dealer or go to
www.infocusstore.com .
3. Elevator foot
Elevator foot drops down when elevator button is
pushed.
4. Elevator button Push to release elevator foot.
10
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 12 mm (0.47inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a
period of 60 seconds.
– 5 –
