INSTALLATIONS
22 MB899 User’s Manual
CON1: SDVO Port Connector
Signal Name Pin # Pin # Signal Name
+12V A1 B1 +12V
+12V A2 B2 +12V
+5V A3 B3 +5V
3.3V A4 B4 3.3V
RESET A5 B5 GND
GND A6 B6 GND
SDVOC_CLK+ A7 B7 SDVOC_CLK-
SDVOC_Blue+ A8 B8 SDVOC_Blue-
GND A9 B9 GND
SDVOC_Green+ A10 B10 SDVOC_Green-
SDVOC_Red+ A11 B11 SDVOC_Red-
GND A12 B12 GND
SDVO TVClkIn+ A13 B13 SDVO TVClkIn-
SDVOB Int+ A14 B14 SDVOB Int-
GND A15 B15 GND
SDVO CtrlData A16 B16 SDVO CtrlClk
SDVOB Clk+ A17 B17 SDVOB Clk-
GND A18 B18 GND
SDVOB Blue+ A19 B19 SDVOB Blue-
SDVOB Green+ A20 B20 SDVOB Green-
GND A21 B21 GND
SDVOB Red+ A22 B22 SDVOB Red-
SDVO Stall+ A23 B23 SDVO Stall-
GND A24 B24 GND
