Jp2: cpu fsb selection(reserved), Jp2 cpu fsb, 533mhz – Intel MB899 User Manual
Page 14: 667mhz, Jp5: lcd panel power selection, Jp3 lcd panel power, For eprom write, Normal, Jp7: clear cmos setting, Jp4 setting
INSTALLATIONS
10
MB899 User’s Manual
JP2: CPU FSB Selection(reserved)
JP2
CPU FSB
533MHz
667MHz
JP5: LCD Panel Power Selection
JP3
LCD Panel Power
3.3V
5V
JP6: 1394 EPROM Write Selection
JP6
1394 EPROM
For EPROM Write
Normal
JP7: Clear CMOS Setting
JP4
Setting
Normal
Clear CMOS
JP8: CompactFlash Slave/Master Selection
JP8
CF Setting
Master
Slave
[
