Intel IQ80333 - Manual (Page 10)

10 Customer Reference Board Manual
Intel® IQ80333 I/O Processor
Introduction
1.3 Electronic Information
1.4 Component References
Table 3 provides additional information on the major components of 80333.
Table 2. Electronic Information
Support Type Location/Contact
The Intel World-Wide Web (WWW) Location: http://www.intel.com
Customer Support (US and Canada): 1-916-377-7000
Table 3. Component Reference
Component Part Number Additional Information
Intel
StrataFlash®
Memory
28F640J3C
• Manufacturer: Intel Corporation
• URL: http://developer.intel.com/design/flcomp/prodbref/298044.htm
Intel(R)
Gigabit
Ethernet
Controller
82545EM
• Manufacturer: Intel Corporation
• URL: http://developer.intel.com/design/network/products/lan/controllers/82545.htm
Rotary Switch DR FC 16
• Manufacturer: Grayhill*
• URL:
http://embrace.grayhill.com/embrace/Item/ASP/Item-Detail.asp?PartNo=94HAB16W&Catalog
GroupID=Series94HBinaryCoded&GroupDisplayLabel=&RestSes=No
Hex Display HDSP-A103
• Manufacturer: Agilent Technologies*
• URL: http://www.semiconductor.agilent.com/cgi-bin/morpheus/home/home.jsp?pSection=LED
AudioBuzzer
DMT 1206
SMT
• Manufacturer: RDI*
• URL: http://www.rdi-electronics.com/products/Audio/DMT-1206-SMT.html
NVSRAM
STK14C88-3
N 35
• Manufacturer: SIMTEK*
• URL: http://www.simtek.com/product-information/datasheets/256K-PDF/STK14C88-3.pdf
CPLD
XC9572XL -
10TQ100C
• Manufacturer: XILINK*
• URL: http://www.xilinx.com/bvdocs/publications/ds057.pdf
Temperature
Sensor
LM75CIMX-3
• Manufacturer: National*
• URL: http://www.national.com/pf/LM/LM75.html
Program-
mable Reset
IC
MAX6306UK
29D3
• Manufacturer: Maxim*
• URL: http://www.maxim-ic.com/quick_view2.cfm/qv_pk/1524
Registered
Buffer
IDT74SSTU3
2864BF
• Manufacturer: IDT* (Integrated Device Technology)
• URL: http://www1.idt.com/pcms/products.taf?catID=97&genID=74SSTU32864
Program-
mable PLL
IDTCSPU877
BV
• Manufacturer: IDT* (Integrated Device Technology
• URL: http://www1.idt.com/pcms/products.taf?catID=112&genID=CSPU877
256 bit 1-wire
EEPROM
DS2430A_TS
OC
• Manufacturer: Maxim*
• URL: http://www.maxim-ic.com/quick_view2.cfm?qv_pk=2913
3.3V
Transceiver
MAX561
• Manufacturer: Maxim*
• URL: http://www.maxim-ic.com/quick_view2.cfm?qv_pk=1544
Battery
Charger
ADP3801
• Manufacturer: Analog Devices*
• URL: http://www.analog.com/UploadedFiles/Data_Sheets/308746738ADP3801_2_0.pdf
