Back Panel Connectors
NOTE
The line out connector, located on the back panel, is designed to power either headphones or
amplified speakers only. Poor audio quality may occur if passive (non-amplified) speakers are
connected to this output.
Figure 18 shows the back panel connectors.
OM15235
USB 2.0
Devices
Line
In
USB 2.0
Devices
Figure 18. Back Panel Connectors
