Intel Desktop Boards D865GBF/D865GLC Product Guide
62
PATA and SATA Submenus
Main Advanced Security Power Boot Exit
` [SATA Port-0 : Xxxxxxxx ]
Type [Auto]
Maximum Capacity [Auto]
Configuration Options
Selected by BIOS
LBA Mode : [Supported]
Block Mode: 16 sectors
PIO Mode : Mode 4
Ultra DMA : Mode 6
Cable Detected : Serial
m o Select Screen
n p Select Item
Enter Select
` Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
There are four IDE submenus: Primary master, primary slave, secondary master, and secondary
slave. Table 21 shows the format of these IDE submenus. For brevity, only one example is shown.
Table 21. SATA and PATA Submenus
Feature Options Description
Drive Installed None Displays the type of drive installed.
Type • Auto (default)
• User Specifies the IDE configuration mode for IDE devices.
Auto fills-in capabilities from ATA/ATAPI device.
User allows capabilities to be changed.
Maximum Capacity None Displays the capacity of the drive.
LBA Mode Control
(Note)
None Specifies LBA mode control.
Block Mode
• Disabled
• Auto (default) Check the hard disk drive’s specifications for optimum
setting.
PIO Mode
(Note)
• Auto (default)
• 0
• 1
• 2
• 3
• 4 Specifies the PIO mode.
continued
