Intel Desktop Board D865GVHZ Product Guide
36
Connecting Hardware Control and Power Cables
Figure 10 shows the location of the chassis intrusion and fan headers, and power connectors.
OM17027
Processor
fan
1
Chassis
front fan
1
Chassis
rear fan
1
12 V
Processor core
voltage connector
1
Main power
connector
1
2
2
Chassis intrusion
1
connector
Figure 10. Location of Hardware Control Headers and Power Connectors
