ABS Curved Back without Mounting Hardware
Recline Only (2GR) and Tilt/Recline (2GTR) with V.S.R.
NOTE: CURV Metal Backs will only attach to Round Back Canes only. Hardware to attach to the Key
Slotted Extruded Back Canes is not available.
NOTE: Wheelchairs with serial number dated for 2005 and after, call a Customer Service Parts Specialist
for additional information on ordering a warranty ABS Back Pan replacement.
NOTE: Overall back height is calculated by measuring from the seat pan surface to the top of the back
pan. Back pan material height can be calculated by subtracting 4-3/4" from the overall back height listed.
Material height listed is rounded off to the nearest whole number.
NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested.
This will allow the Loop Fastener Adhesive on the Back Cover to attach properly.
#3 Back Assembly w/o Hardware (16" - 19" W)
Overall
Back
Height
Material
Back
Height
16" Wide 17" Wide 18" Wide 19" Wide
1090592-NLA 1090591-NLA 1090590-NLA 1090589-NLA
15" 20"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090599-NLA 1090598-NLA 1090597-NLA 1090596-NLA
16" 21"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090606-NLA 1090605-NLA 1090604-NLA 1090603-NLA
17" 22"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090613-NLA 1090612-NLA 1090611-NLA 1090610-NLA
18" 23"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090620-NLA 1090619-NLA 1090618-NLA 1090617-NLA
19" 24"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090627-NLA 1090626-NLA 1090625-NLA 1090624-NLA
20" 25"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
1090634-NLA 1090633-NLA 1090632-NLA 1090631-NLA
21" 26"
See Note(s) A See Note(s) A See Note(s) A See Note(s) A
A - No longer available. Must be ordered as separate components, Item 1 (Back Pan) and Item 2 (Back Cushion Assembly). NOTE:
50
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-026
