Vent Tray Assembly without Mounting Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1115816 Vent Tray Assembly 1 1 1 A,B
1113258 Strap and Buckle Assembly 1 1 2
1113256 Vent Tray Linkage Assembly - Right 1 1 3
1113636 Tube, Vent Tray Support, Black 1 1 4
1044214 Nut, Hex with Nylon Cap (1/4-20) 1 2 5
1025457 Spacer, Coved (1/4 x 3/4 x 11/32") 1 4 6
1115813 Plug, Slide Tube 1 2 7
1113257 Vent Tray Linkage Assembly - Left 1 1 8
1026104-NLA NLA - Spacer 1 2 9
1072692 Lockwasher, Split (5/16") 1 2 10
1115822 Spacer, Vent 1 2 11
1007453 Lockwasher, Split (1/4") 1 2 12
1019590 Screw, Socket Button Head (1/4-20 x 1-5/8") 1 2 13
1072319 Screw, Socket Button Head (#10-32 x 1/2") 1 2 14
1070587 Washer, Flat (3/16 x 5/8 x 1/16") 1 2 15
1079635 Bushing, Flange 1 2 16
1025736 Locknut (1/4-20) 1 4 17
1008432 Screw, Socket Button Head (1/4-20 x 1-1/4") 1 2 18
1006773 Screw, Socket Button Head (1/4-20 x 1/2") 1 4 19
1115820 Bracket, Vent Tray, Black 1 1 20
1118361 Decal, Warning, Approved Charger and Harness 1 1 21
1114968 Tray, Vent 1 1 22
1125645 Spring, Dark Yellow, EXTRA Heavy Duty 1 2 C,D
A - Includes items 2-22 and used for 2GT, 2GR and 2GTR systems. When adding a vent tray assembly to extruded back
canes for the first time, see page titled "Vent Tray Kit For Extruded Back Canes" and order item number 1
B - When Center Mount Riggings are present and a customer is adding a Vent Tray for the first time in the field, additional
Invacare Technical Assistance may be required. Call 1-800-832-4707 for instructions.
C - Not Shown. EXTRA Heavy Duty Springs must be ordered as well when a vent tray assembly is requested for the first time.
D - Spring color changed from Sunny Yellow to Dark Yellow 3/22/10. It is recommended to order springs in pairs to
match color and maintain equal spring tension on both sides of the wheelchair
