Center Mount Rigging KIT (CTMT-T/CTMT-TL)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1121011-NLA NLA - Kit, Adjustable Length Center Mount Rigging
2GTR Short (12-1/4" - 16-1/2") 1 1 1 A
1121012-NLA NLA - Kit, Adjustable Length Center Mount Rigging
2GTR Long (17-1/4" - 21-3/4") 1 1 1 B
1095502 Package, Tie Wrap (11-1/2" L) 10 2 2
1028513 Screw, Socket Head (#10-32 x 1-1/4") 1 1 3
1113236 Spacer (3/16 x 5/16 x 3/4") 1 1 4
1086207 Nut, Square (#10-32) 1 1 5
1113375 Pin, Quick Release (5" Long) 1 1 6
1121079 Cable/Brake Assembly w/ Ratchet Housing and
Glide Bearing 1 1 7
1071736 Screw, Shoulder Hex Socket Head (5/16" x 1-5/8",
1/4-20) 1 1 8
1025736 Locknut (1/4-20) 1 1 9
1117260 Center Mount Rigging, 2GTR (12-1/4 - 16-1/2"
Range) 1 1 10
1117261 Center Mount Rigging, 2GTR (17-1/4 - 21-3/4"
Range) 1 1 10
1118368 Instruction Sheet, Center Mount Rigging Kit 1 1 C
A - Compatible with 16"-17" and 20"-21" seat depths
B - Compatible with 18"-19" and 22" seat depths
C - Instruction Sheet is Not Shown. NOTE:
