Interface Hardware and Tilt Actuator
(To Attach 2GT, 2GTR To The Battery Box)
Tilt Only (2GT) and Tilt/Recline (2GTR)
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1082778 Actuator Motor Assembly, Tilt 1 1 1 E
1105039 Bushing (3/8 x 5/8 x 1/2") 1 2 2
1070411 Bolt, Shoulder (3/8 x 2-1/2") 1 1 3
1026158 Locknut (5/16-18) 1 8 4
1082877 Bar, Clamp, Black 1 2 5
1113618 Guide, Linear - Short 1 2 6
1113594-NLA NLA - Pivot Assembly, Rear 1 1 7
1091869 Screw, Socket Flat Head w/ Patch (1/4-20 x 3/4") 1 6 8
1064267 Locknut (5/16-18) 1 6 9
1114962 Screw, Socket Head (5/16-18 x 1") 1 4 10 B
1108429 Screw, Socket Head w/ Patch (5/16-18 x 1-1/4") 1 4 10 C
1031665 Screw, Shoulder Hex Socket Head (3/8 x 1-1/2",
5/16-18) 1 1 11
1113604 Pivot Assembly, Front 1 1 12
1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 10 13
1043629 Screw, Hex Head w/ Patch (5/16-18 x 1-1/4") 1 6 14
1118370 Decal, Warning, 2GTR Seat Repositioning 1 2 15
1120348 Kit, Bracket w/ Decal, Black - Right (2GTR) 1 1 16
1120349 Kit, Bracket w/ Decal, Black - Left (2GTR) 1 1 16
1071955 Screw, Socket Button Head (5/16-18 x 3/4") 1 6 17
1028769 Locknut (5/16-18) 1 4 18
1114964 Bracket, Lower Interface, Black - Right 1 1 19 B
1114965 Bracket, Lower Interface, Black - Left 1 1 19 B
1140829 Bracket, Lower Interface, Black - Right 1 1 19 C
1140830 Bracket, Lower Interface, Black - Left 1 1 19 C
1121117-NLA NLA - Shim, Short Seat Guide Slide 1 2 20 D
See Note See Footnote 1 1 21 A,H
1140059 Kit, Actuator Braking Module w/ Instruction Sheet 1 1 22 F
1141508 Instruction Sheet, Actuator Braking Module 1 1 G
A - Includes items 1-20 and used to attach a 2GT or 2GTR to the battery box. When item 21 is ordered, item19 Lower
Interface Bracket made after 12/18/05 will be shipped. The seat to floor height will be raised 1/4".
B - Before 12/19/05
C - After 12/18/05
D - Item 20 is no longer used after 12/18/05
E - Actuator Braking Module added to Tilt Actuator and is backward compatible to all systems manufactured before 5/18/06.
The addition of the braking module eliminated the requirement of a Heavy Duty Tilt Actuator.
F - Actuator Braking Module can be assembled in the field on seating systems manufactured before 5/18/06 as well. Must
verify with an Invacare Technician when a kit is required.
G - Not Shown
H - Part number is no longer available as a service part.
NOTE:
