ABS Curved Back without Mounting Hardware
Tilt Only (2GT)
NOTE: CURV Metal Backs will only attach to Round Back Canes only. Hardware to attach to the Key
Slotted Extruded Back Canes is not available.
NOTE: Wheelchairs with serial number dated for 2005 and after, call a Customer Service Parts Specialist
for additional information on ordering a warranty ABS Back Pan replacement.
NOTE: Overall back height is calculated by measuring from the seat pan surface to the top of the back
pan. Back pan material height can be calculated by subtracting 4-3/4" from the overall back height listed.
Material height listed is rounded off to the nearest whole number.
NOTE: Hook Fastener Adhesive Kit must be ordered when a Back Pan or Back Assembly is requested.
This will allow the Loop Fastener Adhesive on the Back Cover to attach properly.
#1 Back Pan (20" - 22" W)
Overall Back
Height
Material Back
Height
20" Wide 21" Wide 22" Wide
1086055-NLA 1086054-NLA 1086053-NLA 16" 20"
1086062-NLA 1086061-NLA 1086060-NLA 17" 21"
1086069-NLA 1086068-NLA 1086067-NLA 18" 22"
1086076-NLA 1086075-NLA 1086074-NLA 19" 23"
1086083-NLA 1086082-NLA 1086081-NLA 20" 24"
1086090-NLA 1086089-NLA 1086088-NLA 21" 25"
NOTE: Wheelchairs with serial number dated for 2005 and after, call a Customer Service Parts Specialist for additional information on
ordering a warranty ABS Back Pan replacement.
#2 Back Cushion Assembly (16" - 19" W)
Overall
Back
Height
Material
Back
Height
16" Wide 17" Wide 18" Wide 19" Wide
1097406 1097405 1097404 1097403 16" 20"
1097413 1097412 1097411 1097410 17" 21"
1097420 1097419 1097418 1097417 18" 22"
1097427 1097426 1097425 1097424 19" 23"
1097434 1097433 1097432 1097431 20" 24"
1097441 1097440 1097439 1097438 21" 25"
Back cover and foam are sold as a back cushion assembly only.
43
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 03-026
