Icom IC-F9511HT - Manual (Page 9)

4
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 n
Programmable function keys
The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2], [P3] and [P4] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function depends on the programming.
CH UP AND DOWN KEYS
➥
Push to select an operating channel.
➥ Push to select a scan group after pushing and holding
[Scan].
ZONE KEY
Push this key, then push [CH Up] or [CH Down] to select the
desired zone.
What is “zone”?—The desired channels are assigned
into a zone according to the intended use for grouping.
For example, ‘Staff A’ and ‘Staff B’ are assigned into a
“Business” zone, and ‘John’ and ‘Cindy’ are assigned into a
“Private” zone.
SCAN KEY
➥
Push to start and cancel scanning operation.
• When the Power ON Scan or Auto Scan function starts a scan,
push this key to cancel the scan. The canceled scan resumes
after a specified time period.
➥ Push and hold this key for 1 sec. to indicate a scan group,
then push [CH Up] or [CH Down] to select the desired one.
(Depending on the pre-setting.)
SCAN ADD/DEL (TAG) KEY
➥
Push to add the selected channel to or delete it from the
scan group.
1. Push to indicate a scan group, then push [CH Up] or
[CH Down] to select the desired one.
2. Push to add the channel to or delete it from the selected
scan group.
3. Push and hold for 1 sec. to exit the scan group selection
mode.
➥ While a scan is paused on a non-priority channel, push this
key to delete the selected channel from the scan group.
• Depending on the pre-setting, the deleted channel is added to
the scan group again, after the scan is canceled. (Nuisance De-
lete function)
