PANEL DESCRIPTION
n
Front panel— Controller
0 1 c h - 0 1
I C - F 9 5 1 1 H T
o
q e w
y r u t i
!0
q AF VOLUME CONTROL KNOB
Rotate the knob to adjust the audio output level.
• Minimum audio level is pre-programmed.
w FUNCTION DISPLAY (p. 3)
Displays a variety of information, such as an operating
channel number/name, DTMF numbers and audible con-
dition, etc.
e UP/DOWN KEYS
Push to select an operating channel, etc.
*The desired function can be assigned by your dealer. (p. 4)
r 10-KEYPAD
The keypad allows you to enter digits to:
• Select memory channels, tone channels and DTMF codes (when
in the DTMF code channel selection mode)
• Start up with a password
• Input the Individual ID code during P25 mode operation. (De-
pending on the pre-setting)
t BUSY INDICATOR
Lights green while receiving a signal, or when the squelch
is open.
