Supplied Accessories
KEY-STICKER
Microphone
Microphone hanger
and screw set
Separation
cable
DC power cable
Key caps
Housing
Function name
stickers*
2
*
1
Fuses should be installed in the fuse holder of the black and red cables, respectively.
See p. 20 for details.
*
2
Used for labelling the programmable function keys according to their assinged functions.
Mounting bracket
for main unit
Mounting bracket
for controller
Bracket bolts
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
Flat washers
(M5)
Spring washers
(M5)
Nuts (M5)
Flat washers
(M5)
Spring washers
(M5)
Mounting screws
(M5×12)
Self-tapping screws
(M5×16)
Bracket screws
Nuts (M5)
Black and red cables
with fuse holders
Socket terminals
Fuses*
1
Crimp terminals
Binding bands
17
3
CONNECTION AND MAINTENANCE
