7.2.3.5 Register 22: Receive Symbol Error Counter Bit Definitions
7.2.3.6 Register 23: 100BASE-TX Receive Premature End of Frame Error Counter
Bit Definitions
7.2.3.7 Register 24: 10BASE-T Receive End of Frame Error Counter Bit Definitions
7.2.3.8 Register 25: 10BASE-T Transmit Jabber Detect Counter Bit Definitions
7.2.3.9 Register 27: 82555 Special Control Bit Definitions
Bit(s) Name Description Default R/W
15:0 Symbol Error
Counter This field contains a 16-bit counter that increments for
each symbol error. The counter stops when full (and
does not roll over) and self-clears on read.
In a frame with a bad symbol, each sequential six bad
symbols count as one.
-- RO
SC
Bit(s) Name Description Default R/W
15:0 Premature End of
Frame This field contains a 16-bit counter that increments for
each premature end of frame event. The counter
stops when full (and does not roll over) and self-clears
on read.
A frame without a “TR” at the end is considered a
premature end of frame event.
-- RO
SC
Bit(s) Name Description Default R/W
15:0 End of Frame
Counter This is a 16-bit counter that increments for each end
of frame error event. The counter stops when full (and
does not roll over) and self-clears on read. -- RO
SC
Bit(s) Name Description Default R/W
15:0 Jabber Detect
Counter This is a 16-bit counter that increments for each
jabber detection event. The counter stops when full
(and does not roll over) and self-clears on read. -- RO
SC
Bit(s) Name Description Default R/W
15:3 Reserved These bits are reserved and should be set to 0b. 0 RW
2:0 LED Switch
Control Value
000
001
010
011
100
101
110
111
ACTLED
Activity
Speed
Speed
Activity
Off
Off
On
On
LILED
Link
Collision
Link
Collision
Off
On
Off
On
000 RW
