Seat Frames and Frame Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
8881101592 Frame, Aluminum, Color 1 1 1 A
1028769 Locknut (5/16-18) 1 2 2
1111949 Clamp, Footrest 1 2 3
1026911 Screw, Socket Set Cone Point (1/4-20 x 1/2") 1 2 4
40117X021 Bearing (1/2" I.D. x 1-1/8" O.D.) 1 4 5
1000208 Screw, Shoulder Hex Socket Head (5/16" x 3/8",
1/4-20) 1 2 6 B
1046494 Screw, Socket Button Head (5/16-18 x 7/8") 1 2 6 C
1046497-NLA NLA - Washer, Nylon (5/16 x 7/8 x 1/64") 1 4 7
1056328 Plug Button, Black (1") 1 2 8
1098112 Hardware, Frame, A6, Both Sides 2 1 9 D
See Chart #10 Seat Frames 1 1 10
1069421 Screw, Shoulder Hex Socket Head (3/8 x 1",
5/16-18) 1 4 11
1093116 Flange 1 4 12
1095638 Rod, Attaching, Adjustable Height 1 2 13
See Chart #14 Seat Adjustment Assembly 2 1 14
A - Configured Item
B - Chairs built Before 9/16/02. Due to design improvement, this screw was replaced with part nos. 1046494 and 1028769.
C - Chairs built After 9/15/02.
D - Includes items 2-8. NOTE:
8
