Wheels - Rear w/ Handrims - Spoke
(After 9/1/11)
Wheels - Rear w/ Handrims - High Performance (HPS)
When ordering a Spoke Wheel with Handrim attached, the standard rim mounting process uses the
outside holes of the handrim mounting tabs. To use the inside holes to reduce the overall width of the
chair, you must order the wheel and handrim assembled as a special order.
Wheel Style
8 Oblique
Projection
Tire Type
Anodized
Aluminum
Wheel
Assembly
Grey
Plastic Coated
Black
Plastic Coated
8 Vertical
Projection
N/A 1115439 1115623 1049496-NLA
1115622
Pneumatic 24HPS
See Note(s) A
N/A 1115440 1115626 1049500-NLA
1115625 Pneumatic with
Flat Free
24HPS
See Note(s) A
N/A 1115441 1115629 1049504-NLA
1115628
Primo 24HPS
See Note(s) A
N/A 1115442 1115632 1049508-NLA
1115631
Continental 24HPS
See Note(s) A
N/A 1115449 1115650 1091337-NLA
1115649
KIK 24HPS
See Note(s) A
N/A 1115444 1115637 1049555-NLA
1115636
Pneumatic 26HPS
See Note(s) A
N/A 1115445 1115640 1049559-NLA
1115639
Primo 26HPS
See Note(s) A
A - As of (11/8/02) these wheels now have a Black finish. For chairs built Before (11/8/02), it is recommended when one wheel is
requested that the wheels be replaced in pairs. NOTE:
Wheels - Rear w/ Handrims - Spinergy (SPIN)
When ordering a Spoke Wheel with Handrim attached, the standard rim mounting process uses the
outside holes of the handrim mounting tabs. To use the inside holes to reduce the overall width of the
chair, you must order the wheel and handrim assembled as a special order.
Wheel Style
8 Oblique
Projection
Tire Type
Anodized
Aluminum
Wheel
Assembly
Grey
Plastic Coated
Black
Plastic Coated
8 Vertical
Projection
N/A N/A N/A N/A
1112339
Primo
SPIN24
See Note(s) A, B See Note(s) A
N/A N/A N/A N/A
1112349
Primo SPIN25
See Note(s) A, B
N/A N/A N/A N/A
1112344 Primo
SPIN26
See Note(s) A See Note(s) A, B
A - As of (7/15/02) Spinergy Wheels now have 18 spokes instead of 30. For chairs built Before (7/15/02), it is recommended when
one wheel is requested that the wheels be replaced in pairs.
B - As of (11/17/08) Spinergy Wheels changed from black spoke, black hub to a black spoke, silver hub appearance. For chairs
built Before (11/17/08), it is recommended when one wheel is requested that the wheels be replaced in pairs. NOTE:
49
