Axles, Camber Bars, and Wheel Attaching Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
See Chart #1 Axle Tubes 1 1 1
1065886 Ring, Toe-In/Toe-Out Adjusting 1 2 2
1055347 Screw, Hex Head (1/4-28 x 1-1/2") 1 2 3
1083913 Pin, Quick Release 1 1 3 A,B
1026907 Washer (1/4 x 1/2 x 1/16") 1 2 4
1098115 Clamp, Camber without Anti-Tip Mount - Right 1 1 5
1098116 Clamp, Camber without Anti-Tip Mount - Left 1 1 5
1098117 Clamp, Camber with Anti-Tip Mount - Right 1 1 5
1098118 Clamp, Camber with Anti-Tip Mount - Left 1 1 5
1065362 Locknut (1/4-28) 1 2 6
1065887 Ring, Indexing 1 2 7
1080135-NLA NLA - Screw, Hex Head w/ Patch (1/4-28 x 3/4") 1 2 8
1025763 Spring, Torsion with Double Button 1 1 9
1055348 Screw, Hex Head (1/4-28 x 1-3/4") 1 2 10
1097976 Clamp, Tube 1 1 11
1064265 Pin, Quick Release 1 2 12
1066489 Screw, Thread Forming (M4 x 16mm) 1 2 13
See Chart #14 Dual Setting Camber Inserts 1 2 14
1062949-NLA NLA - Decal, Indexing 1 2 15
1040361 Axle, Quick Release w/ Locknut (1/2" x 5") 1 1 16
1043487 Axle, Quad Release 1 1 17
1068038-NLA NLA - Axle, Quick Release (Dome) 1 1 18 C
1113049 Axle, Quick Release w/ Dome Button, Black 1 1 18 D
1065303 Axle, Quick Release w/ Flat Button, Black 1 1 18 E
A - Not Shown
B - Quick Release Pin may be subsituted for Screw (item 3).
C - Q.R. Axle (1068038) had an Anodized Dome finish. Q.R. Axle part no. 1113049, w/ Black dome button, can be used as a
replacement but may want to replace in pairs due to aesthetics.
D - Used on all Spoke Rear Wheels except SPIN24, SPIN25, and SPIN26
E - Used on SPIN24, SPIN25, and SPIN26 Spoke Rear Wheels
NOTE:
33
