Hill Holder Wheel Lock and Attaching Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1026712 Hill Holder Wheel Lock Assembly - Right 1 1 1 A
Bracket, Black 1 1 2
Screw, Socket Button Head (1/4-28 x 5/8") 1 2 3
Screw, Socket Button Head (1/4-28 x 1-1/4") 1 1 4
Washer, Nylon (1/4 x 1/2 x 1/32") 1 7 5
Spacer (1/4 x 1/2 x 1/2") 1 1 6
Locknut (1/4-28) 1 4 7
Link, Stop, Black 1 1 8
Handle, Wheel Lock, Black - Right 1 1 9
Tip, Plastic, Black 1 1 10
NLA - Spacer 1 1 11
Hill Holder Assembly - Right 1 1 12
Screw, Socket Button Head (1/4-28 x 3/4") 1 1 13
1026713 Hill Holder Wheel Lock Assembly - Left 1 1 1 A
Bracket, Black 1 1 2
Screw, Socket Button Head (1/4-28 x 5/8") 1 2 3
Screw, Socket Button Head (1/4-28 x 1-1/4") 1 1 4
Washer, Nylon (1/4 x 1/2 x 1/32") 1 7 5
Spacer (1/4 x 1/2 x 1/2") 1 1 6
Locknut (1/4-28) 1 4 7
Tip, Plastic, Black 1 1 8
Handle, Wheel Lock, Black - Left 1 1 9
Link, Stop, Black 1 1 10
NLA - Spacer 1 1 11
Hill Holder Assembly - Left 1 1 12
Screw, Socket Button Head (1/4-28 x 3/4") 1 1 13
1026352 Kit, Wheel Lock Hardware 2 1 B,C
Bolt, Hex Head Cap (1/4-20 x 3/4") 1 2 14
Washer (1/4 x 5/8 x 3/32") 1 2 15
NLA - Clamp, Half, Threaded 1 2 16
Clamp, Half, Non-Threaded 1 2 17
Washer, Nylon (1/4 x 7/16 x 5/64") 1 2 18
Screw, Socket Head (1/4-20 x 1-1/4") 1 2 19
A - Includes items 2-13
B - Not Shown
C - Includes items 14-19 NOTE:
